Spare modules
FLP-SG50 VS/0
Order number: A04148
- replacement module for FLP-SG50 VS, remote fault signalling
Technical parameters
| Parameter name | Parameter value | |
|---|---|---|
| Type of SPD | T1 | |
| Maximum operating voltage | Uc | 255.00 V AC |
| Short-circuit current rating | ISCCR | 50.0 kA |
| Lightning impulse current (10/350 µs) | Iimp | 50.00 kA |
| Nominal discharge current (8/20 µs) | In | 50.00 kA |
| Voltage protection level | Up | 2.50 kV |
| Ability to independently switch off the following current | Ifi | 50.0 kA |
| Response time | ta | 100 ns |
| Fault indication | red indication field | |
| According to standard | EN 61643-11:2012, IEC 61643-11:2011 | |
| ETIM Class | EC000941 | |
| Customs tariff number | 85363090 | |
| EAN | 8595090541486 |
Files for download
-
Product dimensions
_0.PNG)
-
Basic circuit diagram
